The APC SMT750IC is a line-interactive, cloud-enabled Uninterruptible Power Supply (UPS) designed for IT professionals and network administrators to protect critical equipment such as servers, point-of-sale systems, routers, and switches.
Description
This tower-configured UPS provides reliable power protection during outages and against surges, sags, and brownouts by using Automatic Voltage Regulation (AVR). It outputs a pure sine wave power signal when on battery, ensuring compatibility with active Power Factor Corrected (PFC) electronics.
Key features include:
- SmartConnect: A built-in Ethernet port for cloud-based remote power monitoring, firmware upgrades, and proactive email notifications with recommended.
- SmartSlot: An internal accessory slot for an optional network management card (e.g., AP9630/AP9631) to enable graceful shutdown of physical and virtual servers via PowerChute Network Shutdown software.
- Intuitive LCD Interface: A multi-function LCD status and control console that provides real-time information and allows for local configuration.
- High Efficiency Green Mode: A patent-pending operating mode that bypasses unused electrical components under stable power conditions to achieve very high efficiency without sacrificing protection, reducing utility costs and heat generation.
- User-Replaceable Battery: The sealed lead-acid battery cartridge (APC replacement battery cartridge #RBC48) is user-replaceable and hot-swappable, allowing for maintenance without powering down connected equipment.
Specifications
| Feature | Specification | Source |
|---|---|---|
| Capacity (VA / W) | 750 VA / 500 W | |
| Input Voltage | 230V AC (range 160V – 286V adjustable) | |
| Output Voltage | 230V AC (configurable for 220V, 240V) | |
| Output Connections | 6 x IEC 320 C13 (battery backup), 2 x IEC Jumpers (battery backup) | |
| Input Connection | 1 x IEC 320 C14 | |
| Waveform Type | Pure sine wave (on battery) | |
| Topology | Line Interactive | |
| Typical Backup Time (Full Load) | ~4 to 5 minutes at full load (500W) | |
| Typical Recharge Time | 3 hours to 90% capacity | |
| Interface Ports | SmartConnect (Ethernet), USB, Serial (RS-232), SmartSlot | |
| Dimensions (H x W x D) | 161 mm x 138 mm x 369 mm | |
| Net Weight | 11.8 kg | |
| Warranty | 3 years (repair or replace, excluding battery); 2 years for the battery |
UPC:731304340317
